Description
The Desktop Mechanical Heated Ultrasonic Cleaner YR05234 // YR05243 series offers exceptional cleaning performance with a variety of internal capacities and high cleaning accuracy. This powerful ultrasonic cleaner can efficiently remove tiny dirt particles and clean deep holes, fine seams, and hidden surfaces of workpieces.
Market Price
Ultrasonic cleaners like the YR05234 // YR05243 series generally range from around 1000 USD to 1800 USD in the market. This price range reflects the advanced features and reliability of these devices, making them a worthwhile investment for precision cleaning needs.
Frequently Asked Questions
Q: How does an ultrasonic cleaner work?
A: It uses high-frequency sound waves to create cavitation bubbles in the liquid, which effectively remove dirt and debris from all surfaces.
Q: Can this cleaner be used with any liquid?
A: While it can work with various liquids, it’s recommended to use solutions specifically designed for ultrasonic cleaning.
Advantages and Disadvantages
The YR05234 // YR05243 ultrasonic cleaner boasts multiple advantages, including superior cleaning efficiency, reduced noise levels, and robust stainless steel construction. A potential disadvantage is that, like all ultrasonic cleaners, it requires proper maintenance to ensure longevity and consistent performance.
Product Use in the Field
Widely used in labs, industrial centers, and workshops, the YR05234 // YR05243 helps clean delicate instruments, intricate mechanical parts, and components requiring thorough cleaning. Its ability to reach crevices makes it indispensable in many fields.
Recommendations
To maximize the life and efficiency of your ultrasonic cleaner, regularly change the cleaning solution and ensure the unit is not overloaded with items. For best results, select the appropriate temperature and cleaning duration based on the materials being cleaned.
Features
- MCU-sweep ultrasonic generator for superior performance.
- High Q value transducer for efficient energy conversion and longevity.
- Durable tank with staple-free bonding for extended service life.
- Digital heating control with temperatures up to 80℃.
- Stainless steel construction for corrosion resistance.
Technical Specifications
| Model | Internal Dimensions | External Dimensions | Volume（L） | Gross Weight (KG) | Ultrasonic Power(W) | Heating Power(W) | Drain valve | Frequency (KHz) | Time (Min) | Heating Temperature(℃) |
| YR05234 | 240*135*100 | 268*170*243 | 3.2 | 4.77 | 120 | 100 | no | 40 | 1-60 | 30~80 |
| YR05235 | 240*135*150 | 268*170*290 | 5.0 | 5.4 | 120 | 200 | no | 40 | 1-60 | 30~80 |
| YR05236 | 300*150*100 | 325*178*243 | 4.8 | 5.65 | 180 | 200 | no | 40 | 1-60 | 30~80 |
| YR05237 | 302*150*150 | 325*178*290 | 6.8 | 6.2 | 180 | 200 | no | 40 | 1-60 | 30~80 |
| YR05238 | 300*240*150 | 368*270*290 | 11 | 8.5 | 240 | 300 | yes | 40 | 1-60 | 30~80 |
| YR05239 | 330*300*150 | 397*320*317 | 15 | 11.5 | 360 | 400 | yes | 40 | 1-60 | 30~80 |
| YR05240 | 330*300*200 | 397*320*368 | 20 | 12.5 | 360 | 400 | yes | 40 | 1-60 | 30~80 |
| YR05241 | 500*300*150 | 560*320*317 | 22 | 14.5 | 480 | 500 | yes | 40 | 1-60 | 30~80 |
| YR05242 | 500*300*200 | 560*320*385 | 30 | 16.0 | 600 | 500 | yes | 40 | 1-60 | 30~80 |
| YR05243 | 500*300*200 | 560*320*385 | 28 | 16.0 | 600 | 500 | yes | 40 | 1-60 | 30~80 |
