Description
The Doppler Fetal Monitor YR02180 is a versatile and advanced semi-modular parameter patient monitor designed for use in operating theaters and intensive care units. Featuring a 17-inch LCD screen, it provides users with a comprehensive view of vital parameters, including ECG, SpO2, temperature, non-invasive blood pressure (NIBP), respiration, and pulse rate/heart rate. The standard configuration includes a 5-lead ECG, Respiration, Dual-Temp, SpO2, and NIBP, all of which can be enhanced with optional features such as a touchscreen interface, advanced monitoring options like Masimo or Nellcor SpO2, and additional accessories like a trolley or wall mount. This device ensures precise readings with high accuracy and reliability, making it an indispensable tool in any medical setting.
Market Price
The Doppler Fetal Monitor YR02180 is priced in the market between $3500 and $4200, offering a valuable investment for healthcare facilities seeking robust monitoring solutions. This price range reflects the advanced features and capabilities of the monitor, setting it apart from simpler models. Customers are encouraged to explore the cost-effectiveness of this device through our platform, where they can generate an automatic quote via Kalstein Plus.
Frequently Asked Questions
What kind of parameters can the Doppler Fetal Monitor YR02180 measure? The monitor measures vital signs including ECG, SpO2, temperature, NIBP, respiration, and heart rate.
Is the monitor suitable for all patient types? Yes, with its wide range of settings and configurations, it can be tailored to adult, pediatric, and neonatal patients.
Can the monitor be upgraded with additional features? Yes, users can opt for additional modules such as a touchscreen, different SpO2 options, and more.
Advantages and Disadvantages
Advantages: The Doppler Fetal Monitor YR02180 offers high accuracy and reliability, a large display screen, customizable configurations, and the ability to upgrade with optional features. Disadvantages: The initial investment may be high for some facilities, and complex features require thorough training for proper use.
Product Use in the Field
In real-world scenarios, the Doppler Fetal Monitor YR02180 is deployed in operating theaters for continuous patient monitoring during surgery and in intensive care units for critical patient observation. Its modular design allows practitioners to adapt the unit according to specific medical needs, enhancing patient care and ensuring timely interventions when needed.
Recommendations
For optimal performance of the Doppler Fetal Monitor YR02180, it is recommended to undergo comprehensive training to maximize its potential. Regular maintenance and software updates will further ensure device longevity and accuracy. Healthcare facilities should leverage the Kalstein Plus platform to receive customized quotes and support.
Features
- 17-inch LCD screen
- ECG monitoring with 5 or 3 lead configurations
- Dual-Temp channels and SpO2 monitoring
- Non-invasive blood pressure and respiration monitoring
- Numerous optional upgrades for customization
Technical Specifications
| Model | YR02180 | |
|
ECG
|
Lead mode | 5 Leads(RA,LA,LL,RL,V) |
| Connection method | I, II, III,AVR,AVL,AVF,V | |
| Lead Mode | 3 Leads (RA,LA,LL) | |
| Connection method | I, II,III | |
| Gain | x250, x500, x1000, x2000 | |
| Accuracy | ±5% | |
| Resolution | 1bpm | |
| Sensitivity | >200(uVp-p) | |
| Differential input impedance | ≥5MΩ | |
| ST segment Monitoring Range | ||
| Measure Range | -1.0~+1.0mV | |
| Measure Accuracy | -0.8mV~+0.8mV | |
|
Heart Rate
|
Measuring range | 40~240bpm |
| Accuracy | ±3bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200UVp-p | |
|
Respiration
|
Method | Impedance between R-F(RA-LL) |
| Measuring Impedance Range | 0.3~3.0 MΩ | |
| Bandwidth | 0.1~2.5Hz | |
| Respiration Rate | Adult: 7~120BrPM | |
| Neo/Ped | 7~150BrPM | |
| Resolution | 1 BrPM | |
| Accuracy | ±2 BrPM | |
|
NIBP
|
Method | Oscillometric |
| Measuring Interval in AUTO Mode | 1,2,3,4,5,10,15,30,60,90,120,180,240(Min) | |
| Measuring Period in STAT Mode | 5 Min | |
| Pulse Rate Range | 40~240bpm / 40~150bpm | |
| Alarm Type | SYS, DIA, MEAN | |
| Resolution | ||
| Pressure | 1mmHg | |
|
SPO2
|
Display | Number of SPO2,waveform of capacity,Pulse |
| Measuring range | 0~100% | |
| Resolution | 1% | |
| Accuracy | 70~99% (±2%) | |
| Pulse rate range | 0~300bpm | |
|
TEMP
|
Channel | 2 |
| Measuring and Alarm Range | 0~50ºC | |
| Resolution | 0.1ºC | |
| Accuracy | 0.1ºC | |
| Actualization interval | about 1 Second. | |
| Average Time Constant | <10 Second. | |
