Description
- 7-inch colored capacitive touch screen with high resolution (1024*600) and high sensitivity.
- Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
- It supports wireless bluetooth printing and PC connection. Real-time data transfer to mobile phone via bluetooth is optional.
- Smart electrode status display to ensure accurate use.
- Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
- pH mode: P813 Bench Top pH/mV/Conductivity/TDS/ meter
- Conductivity mode: Auto recognition of 25 buffers with three kinds of options: Europe & USA, NIST and China. Support 1, 2, 3 point calibration.
Technical Specifications
Model | YR01828 | |
Cond.
|
Measuring range
|
Conductivity: |
(0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
(200~2000)μS/cm, (2.00~20.00)mS/cm | ||
(20.0~200.0)mS/cm, | ||
(200~2000)mS/cm (K=10) | ||
TDS:(0 ~ 100)g/L | ||
Salinity:(0 ~ 100)ppt | ||
Resistivity:(0 ~ 100)MΩ·cm | ||
Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
Temp. compensation range | (0 ~ 50)ºC, auto | |
Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
Reference Temp. | 25ºC,20ºC,18ºC | |
Temp.
|
Range | (-10 ~ 110)ºC |
Resolution | 0.1ºC | |
Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
Other
|
Display | 7-inch colored capacitive touch screen |
Data storage | 1000 sets | |
Power | 12V/1A | |
Output | USB, RS232, Bluetooth | |
Ambient Temp. | 15 ~ 30 ºC | |
Ambient Humidity | ≤85% | |
IP grade | IP54 | |
Dimensions/N.W. | 240×170×70mm/600g | |
Shipping Size/G.W. | 470x430x85mm/2.6kg |
